(1) Working principle: The dust generated by grinding the workpiece on the operating table is sucked into the bottom and sides, then filtered by the built-in dust filter cartridge and falls into the drawer at the bottom. Clean air is discharged from the top of the device;
(2) Dust removal efficiency: about 99%;
(3) Installation method: All-in-one structure, only need to connect electricity and gas to use.
- Product Details
- Inquiry
- Products Recommended
Product Details
Grinding table selection configuration table | |||||||
Model | Power | Air volume | Full pressure | Filter cartridge | Filter cartridge | Filtration area | Length, width and height |
JG-DMT-2200-2 | 2.2KW | 1688-3517 | 1300-792 | 2 | Φ325*500 | 16 | 800*1100*1600 |
JG-DMT-2200-2 | 2.2kw | 1688-3517 | 1300-792 | 2 | Φ325*500 | 16 | 1200*1200*1600 |
JG-DMT-3000-2 | 3.0kw | 3800-4600 | 1900-1740 | 2 | Φ325*500 | 16 | 1500*1200*1600 |
JG-DMT-4400-2 | 4.4kw | 1688-3517m3/h×2 | 1300-792pa×2 | 2 | Φ325*500 | 16 | 2000*1000*1600 |
JG-DMT-4400-4 | 4.4kw | 1688-3517m3/h×2 | 1300-792pa×2 | 4 | Φ325*500 | 32 | 2000*1200*1600 |
JG-DMT-6000-5 | 6.0kw | 3800-4600m3/h×2 | 1900-1740pa×2 | 5 | Φ325*500 | 40 | 3000*1200*1600 |
